Add to Cart
About product
Product Technical Data
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991702 |
| Approval | RCM trademark c UL us listed (OL) |
| Rated operating distance | 1.5 mm |
| Assured operating distance | 1.21 mm |
| Ambient temperature | -25°C-70°C |
| Switching output | PNP |
| Max. switching frequency | 5000 Hz |
| Max. output current | 200 mA |
| Short circuit current rating | Pulsed |
| Reverse polarity protection | For all electrical connections |
| Electrical connection | Cable |
| Cable length | 2.5 m |
| Size | M8x1 |
| Product weight | 53 g |
| Material housing | PA High-alloy stainless steel |
| Switching status indication | Yellow LED |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
Data sheet – Standard switching distance, basic version
There are many specifications of connectors, price and delivery time. Welcome to enquiry.
