High Frequency Pneumatic Solenoid Control Valve TM-08 , VT307-02
High Frequency Pneumatic Solenoid Control Valve G1/8 , G1/4 Port Size
High Frequency up to 100cycle/sec Solenoid valve TM and VT307 port size G1/8,G1/4 Two position Three Way Direct acting MAC and SMC equvalent
Quick Detail:
1. Size: G1/8,G1/4
2. Dust-Proof protection
3. Two position Three way function pattern
4. Last response time,low consumption,big flow,long service life
5. AC type TM High Frequency solenoid valve,SMC type VT307 series High Frequency Solenoid valve
6 Working Frequency up to 100 cycle/Sec
7. Pattern direct acting type
Applications:
TM and VT307 series High frequency solenoid valve will not be impacted by the working pressure,can get low consumption and big flow rate can be used for air blowing,control single acting cylinders,air distribution,presure selection,and Vacuum equipment etc
Specifications:
| ORDERING CODE | ||
| TM | 08 | DC24V |
| Type | Port Size | Voltage |
| TM:MAC Type High Freqency Direct acting Solenoid valve | 06:G1/8" | DC24V:24VDC |
| DC12V:12VDC | ||
| 08:G1/4" | AC220V:220VAC | |
| AC110V:110VAC | ||
| VT307 | 02 | DC24V |
| Type | Port Size | Voltage |
| VT307:SMC Type High Freqency Direct acting Solenoid valve | 02:G1/4" | DC24V:24VDC |
| DC12V:12VDC | ||
| 01:G1/8" | AC220V:220VAC | |
| AC110V:110VAC | ||
| SPECIFICATION | ||||
| Model No | TM-06 | TM-08 | VT307-01 | VT307-02 |
| Working Medium | Compressed 40 Micron Filtered Air | |||
| Position And Way Numbers | Two Position Three Way | |||
| Protection Structure | Dust-Proof | |||
| Port Size | G1/8" | G1/4" | G1/8" | G1/4" |
| Motion Pattern | Direct Acting | |||
| Working Pressure | 0~0.8MPa | |||
| Max.Working Frequency | 100 cycle/Sec | 10 Cycle/Sec | ||
| Operating Temperature | -5~50℃ | |||
| Voltage Tolerance | ±10% | |||
| Insulation&Protection Class | B Class | |||
